SYSTEM |
Article |
PMB728G840 |
Name |
MultiBoard |
System Type |
MultiBoard |
System Form Factor |
All-in-One |
Built-in Devices |
Android based PC: ARM Cortex A9 / 1.5GHz / 1.5G RAM / 8G ROM
Intel/Windows 10 Pro based PC |
PROCESSOR |
CPU |
Intel® Core™ i7-4790S Processor |
Internal Clock Rate |
3.2 GHz |
CPU Core Quantity |
4 |
Max. CPU Bus Clock Rate |
5 GT/sec |
CPU Socket Standard |
Socket 1150 |
CPU Installed Quantity |
1 |
CPU Maximum Quantity Supports |
1 |
Installed L2 Cache Memory Storage Capacity |
1 MB |
Installed L3 Cache Memory Storage Capacity |
8 MB |
Features |
Supports 22 nm Processors |
Quantity of Mainboards Supported |
1 |
MEMORY |
Memory Type |
DDR3 SDRAM |
Memory Form Factor |
SODIMM 204-pin |
Memory Speed |
1333MHz/1600MHz |
Installed System Memory Storage Capacity |
8 GB |
Maximum Installable System Memory Storage Capacity |
16 GB |
STORAGE |
Storage Type |
Solid State Drive |
Storage Quantity |
1 |
Storage Capacity |
256 GB |
DISPLAY |
Display Form Factor |
Built-in |
Display Type |
LED |
Display Technology |
LED Edge light |
Viewable Display Diagonal Length |
84" | 213 cm |
Maximum Resolution |
3840x2160 |
Image Aspect Ratio |
16:9 |
Pitch Type |
Dot Pitch |
Pitch Width |
0.484 mm |
Image Brightness |
350 cd/m^2 |
Image Contrast |
1 600 : 1 |
Maximum Response Time |
8 |
Image Max. V-View Angle |
178 ° |
Image Max. H-View Angle |
178 ° |
Monitor Compliant Standards |
VESA FDMI
RoHS |
Display Features |
LED Backlight
Infrared Touch-screen, 10 points
Lifetime 30000h
MOHS 7 Steel Glass Protection, 4 mm
Ultra HD |
VIDEO OUTPUT |
Video Controller Form Factor |
Plug-in-Card |
Video Card Installed Quantity |
1 |
Video Chipset |
Nvidia GeForce GT 730M |
Video Memory Type |
Video Controller Memory |
AUDIO OUTPUT |
Audio Controller Form Factor |
integrated |
Audio Output Mode |
Stereo |
Compliant Audio Standards |
High Definition Audio |
SPEAKER |
Audio Output Mode |
Stereo |
Number of Speakers |
2 |
NETWORKING SPECIFICATIONS |
Networking Form Factor |
Integrated |
LAN |
Gigabit Ethernet |
Wi-Fi |
IEEE 802.11a
IEEE 802.11g
IEEE 802.11n |
Bluetooth |
Bluetooth 4.0 |
INTERFACE PROVIDED |
LAN |
2 (RJ-45) |
USB2.0 |
8 (4-pin USB (type A)) |
USB3.0 |
3 (USB 3.0 (type A)) |
VGA |
5 |
Composite Video Input |
1 |
HDMI |
5 |
Audio Interface |
3 (3.5-mm minijack) |
S/PDIF-out Coaxial |
1 |
Audio Line-Out |
1 (3.5-mm minijack) |
Serial |
1 (RS-232) |
Headphones |
1 (3.5-mm minijack) |
Microphone-In |
1 (3.5-mm minijack) |
Mini DisplayPort |
1 |
SOFTWARE |
Software Included |
Prestigio EasiNote
Prestigio EasiSign
Prestigio EasiShow
Prestigio EasiMeeting
Prestigio EasiConnect
Prestigio mClass: mTeacher |
Name of OS |
Microsoft Windows 10 Professional, Android 4.2 |
POWER |
Power Device Type |
Power Supply |
Power Device Location |
Internal |
Input Voltage |
AC 100-240 V |
Input Frequency |
50/60 Hz |
Power Consumption Operational |
500 W |
Power Consumption Stand By/Sleep |
0.5 W |
MISCELLANEOUS |
Package Type |
Box |
External Colour |
Black |
Included Accessories |
3 Writing Pens
Remote Control
Application and Driver Disk
Quick Start Guide
WiFi antenna |
Cable Included |
Audio Cable
USB Cable
VGA Cable
AC Power Cable |
ENVIRONMENT |
Maximum Operating Ambient Temperature |
40 °C |
Maximum Operating Humidity |
90 % |
Minimum Operating Ambient Temperature |
0 °C |
Minimum Operating Humidity |
10 % |
DIMENSIONS & WEIGHT DEVICE |
Height (mm) |
1187 mm |
Depth (mm) |
99 mm |
Width (mm) |
1980 mm |
Nominal Weight |
107 kg |
WARRANTY |
Warranty Products Returnable |
Yes |
Warranty Term (month) |
12 month(s) |
